ABB AC500 system · Ethernet communication terminal unit

TU508-ETH B8 1SAP214000R0001

The TU508-ETH B8 1SAP214000R0001 is an ABB terminal unit for Ethernet communication interface modules. It provides 24 V DC spring-terminal connections, two 8-pole RJ45 network connectors and capacity for up to 24 I/O channels, depending on the inserted CI5xx module.

PRODUCT TYPEEthernet terminal unit
PLATFORMABB AC500 system
NETWORK2 × RJ45
I/O CAPACITYMAX. 24 CHANNELS
MANUFACTURERABB
CONDITION / WARRANTYOriginal New · One-Year Warranty
ISO CERTIFICATIONISO-Certified Product
VERIFICATION● Product photos and videos provided after inquiry
REQUEST A QUOTE
Informe-se agora
MODEL SEARCHFind a specific part numberOpen the best-matched Moore Automation product page directly.
ABB ● Ethernet communication terminal unit
ABB AC500 ETHERNET TERMINAL UNIT

TU508-ETH B8 1SAP214000R0001

Ethernet communication terminal unit

Max. 24 channels

MODULE ROLE
TU508-ETH B8 1SAP214000R0001 is an ABB terminal unit for Ethernet communication interface modules. It provides spring-terminal field connections and two RJ45 network ports; match the inserted CI5xx communication interface module and wiring arrangement.
CONFIGURATION NOTE
For TU508-ETH B8 1SAP214000R0001, confirm ordering code 1SAP214000R0001, 24 V DC supply, spring-terminal wiring, CI5xx module compatibility, RJ45 connections and I/O-group allocation before replacement.
👩‍💼
WANT THE BEST PRICE?
Frida
Sales Leader 🏆
EMAILsales5@mooreplc.com WHATSAPP+86 153 5940 8275
ORDER NUMBER BREAKDOWN

How the TU508-ETH B8 1SAP214000R0001 reference is structured

TU508
Terminal-unit familyEthernet communication interface modules
ETH B8
Communication / markingEthernet · B8 supplied marking
1SAP214000R0001
Exact ABB order code24 V DC · spring terminals
MANUFACTURER-REFERENCE CHARACTERISTICS

Technical Specifications

ABB AC500 ↗
TU508-ETH B8 1SAP214000R0001 Ethernet communication terminal unit

Engineering data at a glance

Click “+” to expand more specifications.

MODELTU508-ETH B8 1SAP214000R0001
SYSTEMABB AC500
NETWORK PORTS2 × RJ45
I/O CAPACITYMax. 24 channels
ABB Hardware Manual 3ADR010278 identifies TU508-ETH B8 1SAP214000R0001 as a 24 V DC spring-terminal unit for Ethernet communication interface modules.
Official product verification Verify TU508-ETH B8 1SAP214000R0001, the inserted CI5xx module, 24 V DC supply, I/O-group allocation, RJ45 network cabling and terminal wiring before ordering.
GENERAL INFORMATION −
BrandABB
Part numberTU508-ETH B8 1SAP214000R0001
Product typeEthernet communication terminal unit
Product familyABB AC500
Model statusExact ABB order code
PlatformABB AC500
ETHERNET & ORDERING ＋
Communication / markingEthernet
Official order code1SAP214000R0001
Current replacementMatch the installed CI5xx communication interface module
I/O CAPACITY & POWER ＋
Network connectors2 × RJ45, 8-pole
I/O capacityMax. 24 channels in 3 groups of max. 8
Power supply24 V DC
Maximum permitted current10 A via UP, UP3 and ZP
DocumentationABB Hardware Manual 3ADR010278
INSTALLATION & COMPATIBILITY ＋
Reference: Confirm the inserted CI5xx module, grounded DIN rail or wall mounting, 24 V DC supply, network cabling and field-terminal allocation.
Source: ABB Hardware Manual 3ADR010278, section TU507-ETH and TU508-ETH.
FAQ

Questions Buyers Ask Most

What is TU508-ETH B8 1SAP214000R0001 used for?＋

TU508-ETH B8 1SAP214000R0001 is a terminal unit for ABB Ethernet communication interface modules. It provides power, field-terminal and network connections for the inserted CI5xx module.

What is the official order code for TU508-ETH B8 1SAP214000R0001?＋

TU508-ETH B8 1SAP214000R0001 uses ABB order code 1SAP214000R0001; TU508-ETH B8 identifies the Ethernet spring-terminal version.

What power supply and current apply to TU508-ETH B8 1SAP214000R0001?＋

TU508-ETH B8 1SAP214000R0001 is rated for 24 V DC. The maximum permitted total current is 10 A through supply terminals UP, UP3 and ZP.

Which network connectors does TU508-ETH B8 1SAP214000R0001 provide?＋

TU508-ETH B8 1SAP214000R0001 provides two 8-pole RJ45 connectors. Ethernet operation is 10/100 base-TX or 100 base-TX depending on the inserted CI5xx module.

How many I/O channels can TU508-ETH B8 1SAP214000R0001 support?＋

TU508-ETH B8 1SAP214000R0001 supports up to 24 I/O channels, arranged as three groups of up to eight channels; allocation is defined by the inserted Ethernet communication module.

How should TU508-ETH B8 1SAP214000R0001 be mounted and grounded?＋

TU508-ETH B8 1SAP214000R0001 may be mounted horizontally or vertically and grounded through a grounded DIN rail or by screws for wall mounting.

What information should be supplied when ordering TU508-ETH B8 1SAP214000R0001?＋

For TU508-ETH B8 1SAP214000R0001, provide the complete order code, inserted CI5xx module, quantity, 24 V DC wiring, RJ45 network arrangement, I/O-group allocation and mounting details.

CONTACT PRODUCT SPECIALIST

Check your configuration with Frida

Share the complete order number and application details for compatibility, availability and lead-time checking.

CHOOSE A DIRECT CONTACT METHOD
DATA SHEET

Product Information for
TU508-ETH B8 1SAP214000R0001

Official manufacturer-reference status for ABB TU508-ETH B8 1SAP214000R0001.

ABB AC500 Hardware Manual

ABB Hardware Manual 3ADR010278 documents TU507-ETH and TU508-ETH terminal units, including I/O capacity, RJ45 connectors, 24 V DC supply, current limits, mounting and grounding.

OFFICIAL HARDWARE MANUAL ↗

Contact to Get Support

Send the complete model, quantity, and your technical or purchasing question.

Technical statements on this page are based on ABB Hardware Manual 3ADR010278 for TU507-ETH and TU508-ETH.

ABB AC500 PRODUCT RELATIONSHIP

How TU508-ETH B8 1SAP214000R0001 Fits into ABB AC500 system

ABB is the brand; ABB AC500 system is the product family; and TU508-ETH B8 1SAP214000R0001 is an ABB terminal unit for Ethernet communication interface modules, identified by exact order code 1SAP214000R0001.

ABB · BRAND
ABB AC500 systemEthernet communication terminal unit
SYSTEM ROLE

Ethernet communication terminal unit

Provides 24 V DC power and spring-terminal connections for the inserted CI5xx Ethernet communication interface module.

I/O CAPACITY

Max. 24 channels

Three groups of up to eight I/O channels are allocated by the inserted Ethernet communication module.

NETWORK & POWER

2 × RJ45 · 24 V DC

Match the inserted CI5xx module, 24 V DC supply, RJ45 cabling and spring-terminal allocation before replacement.

System relationship: verify order code 1SAP214000R0001, inserted CI5xx module, power wiring, RJ45 network and I/O-group allocation.
APPLICATION AREAS

Application mind map for TU508-ETH B8 1SAP214000R0001

Ethernet Interface IntegrationConnect a compatible CI5xx module to the AC500 Ethernet architecture
Field I/O DistributionAllocate up to 24 I/O channels in three groups of up to eight
APPLICATION CENTER TU508-ETH B8 1SAP214000R0001 24 V DC spring-terminal unit for Ethernet communication modules
Network ConnectivityUse two 8-pole RJ45 ports with the Ethernet mode supported by the inserted CI5xx module
Installation MatchingConfirm grounded DIN-rail or wall mounting, supply terminals, CI5xx module and field wiring before replacement.
