GE IS220PHRAH1B Mark VIe HART Analog I/O Pack
GE IS220PHRAH1B Mark VIe HART Analog I/O Pack
GE IS220PHRAH1B Mark VIe HART Analog I/O Pack

GE IS220PHRAH1B Mark VIe HART Analog I/O Pack

GE MARK VIE · HART-ENABLED ANALOG I/O

IS220PHRAH1B

IS220PHRAH1B is a Mark VIe HART-enabled analog I/O pack with ten analog inputs and two current outputs. It links analog field signals and HART device communication to the control and asset-management systems.

PRODUCT TYPEHART ANALOG I/O
PLATFORMMark VIe
INPUTS10 channels
OUTPUTS2 channels
MANUFACTURERGE
CONDITION / WARRANTYOriginal New · One-Year Warranty
ISO CERTIFICATIONISO-Certified Product
VERIFICATION● Product photos and videos provided after inquiry
REQUEST A QUOTE
Informe-se agora
MODEL SEARCHFind a specific part numberOpen the best-matched Moore Automation product page directly.
GE ● HART-ENABLED ANALOG I/O
MARK VIE

IS220PHRAH1B

HART ANALOG I/O

MARK VIE · PHRA · HART INPUT / OUTPUT

MODULE ROLE
IS220PHRAH1B provides analog input/output and HART communication through a compatible SHRA terminal board.
LONG DESCRIPTION
IS220PHRAH1B supports voltage or current input selection and HART messaging on configured 4–20 mA channels. Ten inputs and two outputs form twelve HART channels served by two modems. A DC-62 connector joins the pack to the SHRA board; two RJ-45 ports provide I/O Ethernet connectivity.
👩‍💼
WANT THE BEST PRICE?
Frida
Sales Leader 🏆
EMAILsales5@mooreplc.com WHATSAPP+86 153 5940 8275
ORDER NUMBER BREAKDOWN

How the IS220PHRAH1B Reference Is Structured

IS
Issuing organizationGE Power, Salem, Virginia
2
Substance designationLegacy non-RoHS designation
20
Assembly levelOne or more PCBAs in an enclosure
PHRA
Functional mnemonicHART analog input/output
H
Technology codeIncludes surface-mount components
1
Assembly variantPHRA H1 hardware variant
B
Compatibility versionBackward-compatibility version B
MANUFACTURER-REFERENCE CHARACTERISTICS

Technical Specifications

GE Mark VIe ↗
IS220PHRAH1B HART ANALOG I/O

Engineering data at a glance

Click “+” to expand more specifications.

ANALOG IN10
ANALOG OUT2
MODEMS2
INPUT ADC16-bit
PHRA has twelve HART-capable channels in total: ten inputs and two outputs, multiplexed across two HART modems.
Module configuration The complete reference IS220PHRAH1B identifies the PHRA H1B HART-enabled pack. HART communication requires a channel configured for 4–20 mA; voltage and ±1 mA input modes do not carry HART messaging.
GENERAL INFORMATION −
BrandGE
Part numberIS220PHRAH1B
Product typeHART Analog I/O Pack
Analog inputs10
Analog outputs2 current-loop outputs
HART channels12, served by two modems
FIELD & NETWORK INTERFACES ＋
Inputs 1–8±5 V or 4–20 mA
Inputs 9–10±1 mA or 4–20 mA
Terminal interfaceDC-62 pin to SHRA terminal board
CONVERSION & SUPPLY ＋
Input converter16-bit A/D
Normal input scan5 ms (200 Hz)
I/O networkTwo RJ-45 Ethernet ports
Nominal pack supply28 Vdc; 27.4–28.6 Vdc range
Maximum supply current0.5 A dc
HART COMMUNICATION ＋
Modem arrangement: Modem A serves inputs 1–5 and output 1; modem B serves inputs 6–10 and output 2. HART messages pass between compatible field devices and the asset-management system.
Source: GEH-6721T, Volume II, PHRA HART Enabled Analog I/O Module, chapter 16; GEH-6725R, section 3.10.
FAQ

Questions Buyers Ask Most

How many channels does IS220PHRAH1B provide?＋

IS220PHRAH1B provides ten analog inputs and two current outputs. All twelve channels can support HART when configured in the applicable current-loop mode.

Can IS220PHRAH1B carry HART on voltage inputs?＋

IS220PHRAH1B supports HART on 4–20 mA channels. Inputs configured for ±5 V or ±1 mA do not support HART communication.

How are HART modems shared in IS220PHRAH1B?＋

IS220PHRAH1B has two modems: one serves inputs 1–5 and output 1, and the other serves inputs 6–10 and output 2.

Which terminal boards connect to IS220PHRAH1B?＋

IS220PHRAH1B connects through a DC-62 interface to the documented SHRAH1A or SHRAH2A terminal board configuration.

What supply is specified for IS220PHRAH1B?＋

IS220PHRAH1B is listed in GEH-6725R with a nominal 28 Vdc supply, a 27.4–28.6 Vdc range and 0.5 A maximum supply current.

Other Available Revisions for the IS220PHRAH1B＋

No other full revision was confirmed as an interchangeable replacement for IS220PHRAH1B. Ask Frida to check the installed hardware and application before selecting another revision.

CONTACT PRODUCT SPECIALIST

Check your configuration with Frida

Share the complete order number and application details for compatibility, availability and lead-time checking.

CHOOSE A DIRECT CONTACT METHOD
DATA SHEET

Product Information for
IS220PHRAH1B

Official manufacturer-manual PDF status for GE IS220PHRAH1B.

Official datasheet status

A direct GE-hosted instruction-manual PDF covering IS220PHRAH1B was not confirmed in the public manufacturer library. For the applicable manual and product documentation, please contact Product Specialist Frida.

CONTACT FRIDA

Contact to Get Support

Send the complete model, quantity, and your technical or purchasing question.

GEH-6721T, Volume II, PHRA HART Enabled Analog I/O Module, chapter 16; GEH-6725R, section 3.10.

GE MARK VIE SYSTEM RELATIONSHIP

How IS220PHRAH1B Fits Mark VIe Control

GE is the manufacturer brand; GE Mark VIe is the product family; and IS220PHRAH1B is the hart analog i/o pack used for analog signals and HART field-device communication.

GE · BRAND
GE Mark VIeHART Analog I/O Pack
SYSTEM ROLE

HART Analog I/O Pack

Combines analog I/O with HART field-device messaging.

MODULE / CONFIGURATION

10 AI · 2 AO · 2 modems

Two HART modems multiplex the twelve configured current-loop channels.

I/O ROLE

IS220PHRAH1B · HART Analog I/O Pack

The SHRA field interface and I/O Ethernet network connect field devices to Mark VIe control.

System relationship: PHRA handles analog conversion and HART messaging, while SHRA provides the field termination and transmitter connections.
APPLICATION AREAS

Application map for IS220PHRAH1B

Process MeasurementsAcquire configured voltage or current-loop analog inputs
Analog Output CommandsProvide current-loop control signals to field equipment
MARK VIE HART ANALOG I/O IS220PHRAH1B IS220PHRAH1B · HART Analog I/O Pack
HART Asset ManagementRelay HART messages between devices and the asset-management system
Field Device DiagnosticsExchange supported HART identification and diagnostic information
