The 6ES7288-2DT32-0AA0 is a Siemens SIMATIC S7-200 SMART EM DT32 mixed digital I/O module with 16 digital inputs and 16 sourcing transistor outputs.
Mixed Digital I/O · 16 DI / 16 Transistor DQ
Click “+” to expand more specifications.
6ES7288-2DT32-0AA0 provides 16 digital inputs at 24 V DC and 16 sourcing transistor outputs, giving a high-density 32-point mixed I/O expansion.
Each transistor output on 6ES7288-2DT32-0AA0 is rated up to 0.75 A per point; load current, inrush and switching frequency must all remain within the official limits.
For 6ES7288-2DT32-0AA0, the transistor outputs are grouped and the total is limited to 3 A per common; distribute simultaneous loads so no common terminal is overloaded.
6ES7288-2DT32-0AA0 measures approximately 70 × 100 × 81 mm and weighs about 257 g; preserve room for the terminal blocks and conductor bend radius.
6ES7288-2DT32-0AA0 uses approximately 185 mA of backplane-bus current and has about 4.5 W power loss, which should be included in the station and cabinet calculations.
The sourcing transistor outputs of 6ES7288-2DT32-0AA0 suit frequent 24 V DC switching better than relay outputs, but inductive actuators still need correct suppression and verified inrush current.
For 6ES7288-2DT32-0AA0, provide the CPU model, 16-input/16-output assignment, 24 V DC supply, output-group currents, inductive-load details, quantity and destination.
Share the complete order number and application details for compatibility, availability and lead-time checking.
Official Siemens documentation for the SIMATIC S7-200 SMART EM DT32 module.
Siemens technical datasheet for 6ES7288-2DT32-0AA0, including channel configuration, electrical ratings, environmental limits, dimensions and weight.
OFFICIAL DATASHEETSend the complete model, quantity, and your technical or purchasing question.
Technical statements on this product page are based on publicly available official Siemens manufacturer documentation.
Siemens is the brand; SIMATIC S7-200 SMART is the PLC family; and 6ES7288-2DT32-0AA0 is the EM DT32 mixed digital I/O expansion model with 16 inputs and 16 transistor outputs.
EM DT32 expands an S7-200 SMART station with 16 digital inputs and 16 sourcing transistor outputs.
STEP 7 Micro/WIN SMART is used to configure the CPU station and commission the S7-200 SMART expansion module.
The module exchanges process data and receives logic power through the S7-200 SMART backplane bus.
